Connect System Cables
Service Module
Telesyn x400 - Installation Guide (Installation of ATI 9400)
1-24
1.18 Connect System Cables
1.18.1 Service Module
1.18.1.1 SMs with RJ45 connectors
Attach the RJ45 end of the Ethernet cable to the specified port on the FE10 card.
FIGURE 1-17
FE10 Cable Connector
FIGURE 1-18
FE10 data cable connectors
Note: Each RJ45 cable connected to the FE10 card should be dressed neatly and tightly. Do
not permit cables to loop.
