Check the Configuration Check software load
Telesyn x400 - Installation Guide (Installation of ATI 9400) 1-30
5. Input a user ID of officer and a password of officer.
6. Check the management logs for any problems by inputting the following:
> SHOW LOG SEVERITY=CRITICAL
> SHOW LOG SEVERITY=MAJOR
> SHOW LOG SEVERITY=MINOR
7. Check for any alarm conditions by inputting the following:
> SHOW ALARMS ALL
8. Determine if there are any faults as a result of performing Steps 6 and 7.
• If any logs are produced, or if an alarm has a status other than INFO, contact your ATI representative and
review the output.
Note: If the MAC card is bad, the following is produced:
- A SYS009 log is generated with text “Can Not Read MAC Address”
- A major alarm is set against the shelf with the text “Can Not Read MAC Address”
• If there are no faults, go to section Check the Configuration.
1.20 Check the Configuration
1.20.1 Check software load
1.20.1.1 ATI 7400
Although control modules and service modules are shipped with release files already present in FLASH mem-
ory, the release file should be compared with the latest software release files that are available from ATI or if this
is a replacement card, the current system loads. See section 1.21 for contact information.
Once a software release file is downloaded onto a network server, copy it to the Control Module FLASH file sys-
tem, load it into FLASH memory, make it the active load, and ensure that when the Control Module reboots this
latest load is always used. If this is a replacement card, make sure that the current system load is loaded into the
card. Also ensure the service module loads are obtained from the control module.
Details on the steps to do this are in section, File Management and Software Release Upgrade of the ATI
User Guide.
1.20.1.2 ATI 9400
The CFC24 in the 9400 comes equipped with optional Compact FLASH (CFLASH). Compact Flash (CFLASH)
is a removable memory card that will insert into the faceplate of CFC24 Control Module. This extra memory can
be used to store release load files, databases, and captured log files. Compact FLASH is a small portable card
