Install the ATI 9400 Chassis into the Rack Ensure all Components for Desired Configuration
Telesyn x400 - Installation Guide (Installation of ATI 9400) 1-12
1.7 Install the ATI 9400 Chassis into the Rack
1.7.1 Ensure all Components for Desired Configuration Present
Using Table 1-1as a guide, ensure that all components used for the installation are present:
• ATI 9400 shelf (includes ATI 9400 chassis and FM7, FC7, PEM7, and MAC)
• Network Module (at least 1) and SFP for each Network Module
• Control Module (1)
• Service Module (at least 1 up to 7)
• FPF (none to 6, depending on the Service Module configuration)
• FPH (none or 1, depending on Network Module configuration)
• Cable for each Service Module (length determined by office configuration)
Note: All of these items can be ordered as required. Refer to your ATI representative for orderable
part numbers. Refer to the Hardware Reference for more information.
5. Enter into your office records the serial number of the chassis, which will be a S/N label on the rear of the
chassis. (This may be needed if the ATI 9400 requires troubleshooting.)
Note: A worksheet to place serial numbers for the ATI 9400 is included at the end of this document,
Table 3-2.
1.7.2 Install the Chassis
1. In an antistatic environment, remove the chassis from its packaging.
2. Note the flanges, which are attached so that the shelf is center-mounted.
Note: If the user wishes to front mount the ATI 9400 chassis, contact your ATI representative.
Figure 1-8 and Figure 1-9 show the different mounting options.
3. Install the bottom mounting bolts in the rack. Tighten until there is a 1/4 inch gap between the bolt flange and
the rack surface.
4. Pick up the ATI 9400 chassis by placing your hands on the inside of the chassis, palms up, and placing in the
rack, lining up the notch on the bottom of the flange with the bottom mounting bolt.
5. Once the shelf is mounted, hand tighten the bottom bolts.
6. Install the remaining mounting bolts. Use a minimum of three bolts for each side, with the other two bolts
used being one of the middle mounting groups and one at the top. Refer to Figure 1-9.
7. Verify the FM7 is installed in the chassis.
