Property Name Description Valid Values
• PRECEDENT
• PROTUNREACH
• PTRPROBLEM
• SOURCEROUTE
• TTL
This can also be set by entering
a value from 0-255.
IGMP Type Specifies the IGMP type of an
IPv4 packet. This can be set by selecting any
one of the following values:
• QUERY
• V1REPORT
• DVMRP
• PIMV1
• CTRACE
• V2REPORT
• V2LEAVE
• MCTRACERESPONSE
• MCTRACE
• V3REPORT
• MRADVERT
• MRSOLICIT
• MRTERMINATION
• any
This can also be set by entering
a 2-byte hexadecimal number
00-FF.
EIPByte01-16 These parameters each specify
the properties of a single byte
field to match in the Layer 3
header and data of a non-IPv4
and non-IPv6 packet. The
eipbyte01 parameter must be
used as the first byte field, and
additional byte fields must
increment sequentially, for
example eipbyte01, eipbyte02,
eipbyte03. Each field must have
a greater offset than the field
that precedes it.
For each byte field you want to
match, specify a byteoffset and
a bytevalue, and optionally, a
bytemask.
Each entry can be set by
entering the following value:
, ,
(e.g. 3,AA,FF)
