6.8 Rapier 24i
Topics:
• Classifiers
• Flow Groups
• Traffic Classes
• Policies
• Ports
• Scheduling
• Quick Setup
• Notes
6.8.1 Classifiers
6.8.1.1 QoS Information Window
Column Name Description
Classifier ID Lists the Rule ID of packet-matching rules
available
6.8.1.2 Add/Modify Classifier
Property Name Description Valid Values
Rule ID
(cannot be
modified)
Uniquely identifies the packet-
matching rule
Range: 1-9999
Egress Port Specifies the egress port on the
switch to match for each
frame.
This can be set by selecting any
of the following values:
• 1-N (where N is the
number of ports
available on the device)
This value can also be set
to "any".
Ingress Port Specifies the ingress port on
the switch to match for each
frame.
This can be set by selecting any
of the following values:
• 1-N (where N is the
number of ports
available on the device)
This value can also be set
to "any".
