Allied Telesis AlliedView-EMS 3.10 QoS MANAGER - Manual (Page 108)

Property Name Description Valid Values
Ingress
Interface Specifies the interface through
which the frame arrives at the
switch. This can be set by selecting the
name of a pre-defined interface
on the device.
This can also be set to "none".
Source VLAN Specifies the VLAN associated
with the frame when it arrives
at the switch. Only valid in
classifiers for software QoS on
egress interfaces.
This can be set by selecting
from a list of available VLANs
or "any".
Destination
VLAN
Specifies the VLAN that the
frame will be transmitted to.
Only valid in classifiers for
software QoS on egress
interfaces.
This can be set by selecting
from a list of available VLANs
or "any".
VLAN Specifies the Destination VLAN
that the packet will be
transmitted on. This can be set by selecting
from a list of available VLANs
or "any".
VLAN Priority Specifies the 802.1p VLAN
priority value in the frame.
Range: any, 0-7
Ethernet
Format
Specifies the Ethernet
encapsulation type of the
packet.
• 802.2
• 802.2-Tagged
• 802.2-Untagged
• EthII
• EthII-Tagged
• EthII-Untagged
• NetwareRaw
• NetwareRaw-Tagged
• NetwareRaw-Untagged
• SNAP
• SNAP-Tagged
• SNAP-Untagged
• any
Source MAC
Address Specifies the source MAC
Address of a packet. This can be set by entering a
MAC address string using the
following format:
• XX-XX-XX-XX-XX-XX
This value can also be set to
"any".
Destination
MAC Address This parameter is the
destination MAC Address of a
packet. This can be set by entering a
MAC address string using the
following format:
• XX-XX-XX-XX-XX-XX
AlliedView™-EMS 3.10 QoS Manager User’s Guide Page 108 of 128
