6.7.6 Scheduling
Column Name Description Valid Values
Port
(cannot be
modified)
Specifies the port ID. This can be set by selecting any
one of the following values:
• port 1 - n (n = number of
ports available)
• none
Max Bandwidth Specifies the maximum
bandwidth permitted on the
port.
This value can be set by
entering a number from 0-
16000000.
Alternatively a value from 0-
16000Mbps can be specified.
0-16Gbps can also be specified.
Scheduler Specifies the method by which
frames on each egress queue is
allocated bandwidth for
transmission onto the line.
The following options are
possible:
• strict to schedule based
on queue number.
Queues with higher
numbers are served first-
before lower numbered
queues in the strict
priority group and WRR,
if there is a mix of the
two types.
• wrr1 to schedule
weighted round robin.
The queue shares
bandwidth with other
queues in the WRR1
group according to their
relative values of
wwrweight. The WRR1
group can transmit
frames when the strict
scheduling group is
empty.
• wrr2 to schedule
weighted round robin.
The queue shares
• Strict
• WRR1
• WRR2
