Property Name Description Valid Values
destination VLAN.
Inner Tag
Protocol ID Specifies the TPID in the
second 802.1Q tag in the
packet. This can be set by entering a 4-
byte hex number from 0000-
FFFF.
This can also be set to "any".
Inner VLAN
Priority Specifies the second 802.1P
field in the packet. Range: any, 0-7
Inner VLAN Specifies the tunnelled VLAN
ID in the second 802.1Q tag in
the packet. This can be set by selecting
from a list of available VLANs
or "any".
Ethernet
Format This parameter specifies the
Ethernet encapsulation type of
the packet. • 802.2-Tagged
• 802.2-Untagged
• EthII-Tagged
• EthII-Untagged
• NetwareRaw-Tagged
• NetwareRaw-Untagged
• SNAP-Tagged
• SNAP-Untagged
• any
Protocol Specifies the protocol of the
packet. This can be set by selecting any
of the following values:
• IP
• IPX
• IPv6
• SNA PATH CONTROL
• PROWAY-LAN
• EIA-RS
• PROWAY
• IPX 802.2
• NETBEUI
• ISO CLNS IS
• IP ETHII
• X.75 INTERNET
• NBS INTERNET
• ECMA INTERNET
• CHAOSNET
• X.25 LEVEL3
• ARP
• XNS COMPAT
• BANYAN SYSTEMS
• BBN SIMNET
• DEC MOP DUMP/LD
AlliedView™-EMS 3.10 QoS Manager User’s Guide Page 86 of 128
