Property Name Description Valid Values
to TOS value in the ToS priority field
will be replaced with the value
in the 802.1p priority field on
IPv4 packets. • no
Flow Group
List Specifies a list of the Flow
Groups currently assigned to
this Traffic Class. Select from a list of available
Flow Group IDs.
6.5.4 Policies
6.5.4.1 QoS Information Window
Column Name Description
Policy ID Lists the ID of Policies available
Description A brief description of the Policy
Traffic Classes List of Traffic Classes associated with this Policy
6.5.4.2 Add/Modify Policy
Property Name Description Valid Values
Policy ID
(cannot be
modified) Specifies the unique identifier
for the Policy. Range: 0-255
Description Specifies a brief description of
the Policy. To set this value, enter an
alphanumeric string from 1-15
characters.
Ingress DSCP
Overwrite
Specifies a replacement value
to write into the DSCP (TOS)
field of the packets.
Range: none, 0-63
Remark Ingress
DSCP
Specifies whether the DSCP
value in ingress packets is
overwritten.
• all
• none
Type of Service Specifies a replacement value
to write into the Type of
Service (ToS) field of IPv4
packets.
Range: none, 0-7
Move TOS to
Priority
Replaces the value in the
802.1p priority field with the
value in the ToS priority field
on IPv4 packets.
• yes
• no
Move Priority
to TOS Replaces the value in the ToS
priority field with the 802.1p
priority field on IPv4 packets. • yes
• no
Send to Mirror Copies the traffic that meets
the criteria of the classifiers to
• yes
