Property Name Description Valid Values
• byteoffset is a decimal
number in the range 0 to
65. This specifies the
location of the byte to
match. It refers to the
offset from the start of
Layer 3, after the Layer 2
encapsulation format of
an Ethernet frame.
• bytevalue is a 2-digit
hexadecimal number.
This specifies the value
of the byte at the frame
position determined by
the byteoffset. The
classifier matches
packets that have this
value at this location.
• (optional) bytemask is a
2-digit hexadecimal
number. This specifies an
eight-bit binary mask to
apply to the field. When
a bit is set to 1 in the
mask, the value of the bit
at the same position in
the byte is used to
determine a match. If
the bytemask is 0, the
corresponding bit is
ignored. The default is ff,
which means the
classifier matches against
all bits in the byte.
6.6.2 Flow Groups
6.6.2.1 QoS Information Window
Column Name Description
Flow Group ID Lists the ID of Flow Groups available
Description A brief description of the Flow Group.
Classifiers List of Classifiers associated with this Flow
Group
