Property Name Description Valid Values
Bandwidth bandwidth available to this
setup. • 0-16000 Mbps (decimal
point supported)
• 0-16 Gbps (decimal point
supported)
Default for VOICE: 128kbps
Default for VIDEO: 256kbps
Port
Assignment Specifies a list of ports that will
be affected by this setup. Select from a list of available
Ports.
Default for VOICE: no ports
Default for VIDEO: no ports
6.6.8 Notes
• Configuring the Port and VLAN properties of a Flow Group, Traffic Class
or Policy will have no effect unless the Action or Default Traffic Class
Action property is set to 'SENDVLANPORT'.
• Values entered for the Maximum Bandwidth traffic class property are
rounded up to the nearest multiple of 648.
• When the Protocol property is configured, the Ethernet Format property
should also be configured.
• To configure the Storm Status property, the switch must be in enhanced
mode.
• When the Storm Status property is configured, the Storm Window and
Storm Rate properties should also be configured.
• Values entered for the Storm Window property are automatically
rounded off to the nearest hundreds.
• When the IP Protocol classifier property is configured to '0', the current
firmware version automatically converts this value to 'NONTCPUDP'.
• Valid values for the VLAN Priority classifier property are 'any' and values
in the range [0-7] inclusive. However, when VLAN Priority is set to 'any',
the current firmware version automatically converts the 'any' value to
'4294967295'. When this happens, any attempt to modify the classifier
will result in the error message: "Parameter VLANPRIORITY, value too
high; maximum is 7."
• When the Protocol property is configured, the Ethernet Format property
should also be configured.
