6.7 AT-x900-24x Series
Topics:
• Classifiers
• Flow Groups
• Traffic Classes
• Policies
• Ports
• Scheduling
• Quick Setup
• Notes
6.7.1 Classifiers
6.7.1.1 QoS Information Window
Column Name Description
Classifier ID Lists the Rule ID of packet-matching rules
available
6.7.1.2 Add/Modify Classifier
Property Name Description Valid Values
Rule ID
(cannot be
modified)
Uniquely identifies the packet-
matching rule
Range: 1-9999
Source MAC
Address Specifies the source MAC
address of the packet. This can be set by entering a
MAC address string using the
following format:
• XX-XX-XX-XX-XX-XX
This can also be set to "any" or
"dhcpsnooping".
Destination
MAC Address This parameter specifies the
destination MAC address of the
packet.
This can be set by entering a
MAC address string using the
following format:
• XX-XX-XX-XX-XX-XX
This can also be set to "any".
Source MAC
Address Mask Specifies the masks to be used
on the Source MAC Address.
When a bit is set to 1 in the This can be set by entering a
MAC address string using the
following format:
