6.3.3.2 Add/Modify Traffic Class
Property Name Description Valid Values
Traffic Class ID
(cannot be
modified) Specifies the unique identifier
for this Traffic Class. Range: 0-511
Description Specifies a brief description of
the Traffic Class. To set this value, enter an
alphanumeric string from 1-15
characters.
Exceed Action Specifies the action to take if
the traffic classes
maxbandwidth is exceeded.
• drop
• remark
Exceed Remark
Value Specifies the DSCP
replacement value for traffic
that exceeds the
maxbandwidth. Range: 0-63
Mark Value Specifies a replacement value
to write into the DSCP (TOS)
field for all packets. Range: none, 0-63
Maximum
Bandwidth Specifies the maximum
bandwidth available to the
traffic class. This can be set by entering a
value using one the following
formats:
• 0-16000000 kbps
• 0-16000 Mbps (decimal
point supported)
• 0-16 GBps (decimal point
supported)
Priority Specifies the priority value in
the IEEE Standard 802.1p tag
control field that traffic
belonging to this traffic class is
assigned.
Range: none, 0-7
Remark
Priority Specifies whether the value of
the priority parameter is used
to set the egress queue
selection for a frame and also
to replace the 802.1p priority
value in the frame, or just to
select the egress queue for the
frame.
• yes
• no
Flow Group
List Specifies a list of the Flow
Groups currently assigned to
this Traffic Class.
Select from a list of available
Flow Group IDs.
