Chapter 4: Installing the Switch and its Power Supplies
70
Connecting AC Power to a Power Supply Module
To power on a switch with one or two AC Power Supply Modules, perform
the following procedure:
1. Position the power cord retaining clip in the up position, as shown in
Figure 28.
Figure 28. Power Cord Retaining Clip in the Up Position
2. Plug the power cord into the AC power connector on the rear panel of
the unit, as shown in Figure 29. Lower the power cord retaining clip to
secure the power cord to the unit.
Figure 29. Connecting the AC Power Cord
Warning: Power cord is used as a disconnection device. To de-
energize equipment, disconnect the power cord.
E3
100-240V
AC ~
100-240V
AC ~
