Management panel, Figure 3: at-ix5-28gpx management panel – Allied Telesis AT-IX5-28GPX User Manual
Page 20
Chapter 1: Overview
20
Management Panel
Figure 3 identifies the components in the management panel on the AT-
IX5-28GPX switch.
Figure 3. AT-IX5-28GPX Management Panel
Console
eco-friendly
Button
Switch
Port
ID LED
Management
USB Port
