Table 14: pin signals for 1000 mbps – Allied Telesis AT-IX5-28GPX User Manual
Page 126
Appendix A: Technical Specifications
126
Table 14 lists the pin signals when a port operating at 1000 Mbps.
Table 14. Pin Signals for 1000 Mbps
Pinout
Pair
1
Pair 1 +
2
Pair 1 -
3
Pair 2 +
4
Pair 3 +
5
Pair 3 -
6
Pair 2 -
7
Pair 4 +
8
Pair 4 -
