Rj-45 style serial console port pinouts – Allied Telesis AT-IX5-28GPX User Manual
Page 127
IX5-28GPX Installation Guide
127
RJ-45 Style Serial Console Port Pinouts
Table 15 lists the pin signals of the RJ-45 style serial Console port.
Table 15. RJ-45 Style Serial Console Port Pin Signals
Pin
Signal
1
Looped to pin 8.
2
Looped to pin 7.
3
Transmit Data
4
Ground
5
Ground
6
Receive Data
7
Looped to pin 2.
8
Looped to pin 1.
