Introduction
M414038 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Serial Plate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are located on the serial
plate as shown.
T458I
1 Serial Plate
2 Junction Box Cover
Conversion Table
Multiply By To Obtain Multiply By To Obtain
Btu .252 kCal Pounds/sq. inch .06895 Bars
Btu 1055 Joules Pounds/sq. inch .070 kg/sq. cm
Inch 25.4 Millimeters Pounds (lbs.) .454 Kilograms
Inches W.C. .036 Pounds/sq. inch Boiler Horsepower 34,479 Btu/hr.
Inches W.C. .249 kPa Boiler Horsepower 34.5 lbs. Steam/hr.
lbf/inch
2
(psi) .0369 kPa CFM .471 Liters/second
ft
3
28.32 Liters kW 3414 Btu/hr.
120 POUND TUMBLER
2
1
2
1
170 POUND TUMBLER
