Specifications and Dimensions
Specifications
120 Pound
170 Pound
Cylinder Size
44 in. x 41 in. (1118 mm x 1041 mm)
50.75 in. x 42.5 in. (1289 mm x 1080 mm)
Cylinder Capacity Dry Weight
120 lbs. (54.4 kg)
170 lbs. (77.1 kg)
Cylinder Motor Horsepower
3/4
3/4
Fan Motor Horsepower
1
3
Air Outlet Diameter
10 in. (254 mm)
12 in. (300 mm)
Maximum Static Back Pressure
0.3 W.C.I. (0.8 mbar)
0.3 W.C.I. (0.8 mbar)
Maximum Airflow
1600 C.F.M. (755 L/sec)
2450 C.F.M. (1156 L/sec)
Gas Models
Net Weight
1275 lbs. (580 kg)
1575 lbs. (716 kg)
Gas Connection
3/4 in. NPT
1 in.
NPT
Gas Consumption
300,000 Btu/hr (316 Mj/hr)
395,000 Btu/hr (421 Mj/hr)
Steam Models
Net Weight
1375 lbs. (625 kg)
1675 lbs. (761 kg)
Steam Connection
3/4 in.
NPT
3/4 in. NPT inlet
1 in. NPT outlet
Steam Consumption
10 bhp (335,000 Btu)
15 bhp (502,500 Btu)
