Horner APG SmartStix HE559MIX977 User Manual
Page 4
PAGE 4
27 FEB 2007
MAN0561-02
4 INTERNAL
WIRING
I/O Connector
To
Controller
SmartStack Inputs
Field
Side
Voltage
Input
Current
Input
Isolated
Common
700K
Ω
300K
Ω
+
_
150
Ω
6V
I/O Connector
From
Controller
SmartStack Outputs
Field
Side
<
Voltage
Output
Current
Output
Isolated
Common
-
+
100
Ω
100
Ω
Mode
Mode
