Page 82
DETAIL A
A
40' GANG LAYOUT
8/30/2012
9DC4012.iam/
40' DISK-CHISEL
40' COULTER-CHISEL
48"
164"
48"
164"
24 1/4"
72 1/2"
122 1/4"
142 1/4"
194 1/4"
214 1/4"
8CC2280F
8CC2280F
8CC2260F
8CC2260F
8CC2260F
8CC2260F
8J3256
8J3266
8J3276
8J3286
8J3266
8J3256
WHEN LOCATING BLADE, USE CENTER
HOLE ON REAR OF BRACKET, AS
SHOWN. DIMENSION SHOWN IS FROM
CENTERLINE OF MACHINE TO THIS HOLE.
0"
16 1/4"
57 1/4"
97 1/4"
137 1/4"
177 1/4"
217 1/4"
0"
37 1/4"
77 1/4"
117 1/4"
157 1/4"
197 1/4"
237 1/4"
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
2-70
