24'-28' hitch & locks, 24’-28’ hitch and cylinder locks -10, Ab c – Summers Disk-Chisel User Manual
Page 110
DETAIL A
DETAIL B
DETAIL C
A
B
C
HITCH-LOCKS
7/13/2012
9CC2412H.iam/
8X0211
5/16" FN
8K8200
8X0203
3/8" FN
8S1124
8X0021A
5/16 X 1"
8D8500
8X0110
3/4 X 1.25"
8X0318
3/4" FW
8D8490
8X0223
1/4" FN
8K8067
8X0000
1/4 X 3/4"
8S1126
8S1120
8A1156
3/8 X 4-1/16 X 5"
8T2040
8P7250
8X0285
1 1/2" N
8T4350
8X0402
8X0440
8T4380
8X0240
1/2" N
8X0303
1/2" LW
8X0234
7/16" LNUT
8K1640
8X0044
7/16" X 3-1/2"
8CC4012
8X0260
3/4" N
8X0306
3/4" LW
8X0120
3/4" X 9"
8S0340
1/2 X 4 X 5 1/4" SQ
8CC4010
8D8522
8CC4000
8CC0600
6-10
SECTION 6 – P
ARTS (24’-28’)
