24'-28' wing transports, 24’-28’ wing transport assembly -12 – Summers Disk-Chisel User Manual
Page 112
DETAIL A
DETAIL B
WING-TRANSPORT
7/27/2010
9DC2412H.iam/
A
B
8T4175
8X0242
NY-LOCK 1/2" N
8L0300
8S0660
8T4177
8X0303
1/2" LW
8X0240
1/2" N
8X0234
7/16" LNUT
8T3620
8X0044
7/16" X 3-1/2"
8CC4140
8T4168
8T3640
8K5515
3/4 X 4 X 6"
8X0234
7/16" LNUT
8X0044
7/16" X 3-1/2"
8X0306
3/4" LW
8X0260
3/4" N
8T4100
8K1100
8K7033
8R6914
8X0077
1/2" X 7-1/2"
8T4174
8S0660
8X0242
NY-LOCK 1/2" N
8X0074
1/2" X 4-1/2"
8T4179
8K9106
8D9108
1/4 X 2" RP
8T1060
6-12
SECTION 6 – P
ARTS (24’-28’)
