Summers Disk-Chisel - Manual (Page 122)

1
1
2
2
A A
B B
GAUGE WHL ASSY W/O HUB 3/8/2013 8T4096.iam/
8T4094
8X0520
ROLL PIN
8X0520
ROLL PIN
A
ROLL PIN "A" INSERTED
INTO THIS HOLE
8T4090
8X0259
3/4" JN
8X0107
3/4 X 2"
8D9110
8T6000
8X0327
1 1/4" FW
8X0290
1-1/4" SLOT NUT
8X0242
NY-LOCK 1/2" N
8X0202
3/8" LN
8T6020
8X0008
3/8 X 2"
8X0067
1/2-13NCX2-1/4"
8T6010
6-22
SECTION 6 – PARTS (32’-40’)
