Summers Disk-Chisel - Manual (Page 49)

CC-DC DEPTH CNTRL HYD 9/12/2012
8T1045
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8J6010
3/4-16ORB X #6JIC(M) 90° ADP
8T1050
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8T1055
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8T1060
8J5520
3/4" ORB X #10 STR
8J5520
3/4" ORB X #10 STR
24' - 28' MACHINES
TO TRACTOR
TO 8T1055
8T1060
TOP VIEW
8T1010
POPPET
8T1008
PLASTIC PLUNGER
REPAIR KIT
8D3212
3/4" ORB TIP ISO
8J5510
3/4" ORB X #6 JIC(M)
8J5520
3/4" ORB X #10 STR
8N6570
3/4" X 570"
8N4198
1/2" X 198"
8N4228
1/2" X 228"
8N4198
1/2" X 198"
8N3534
3/8" X 534"
SECTION 2 – HYDRAULIC SET
-UP
(24’
- 28’)
2-37
