36' disk-chisel and coulter-chisel layout, 36' disk-chisel 36' coulter-chisel – Summers Disk-Chisel User Manual
Page 80
DETAIL A
A
36' GANG LAYOUT
8/30/2012
9DC3612.iam/
36' DISK-CHISEL
36' COULTER-CHISEL
48"
164"
48"
164"
24 1/4"
72 1/2"
120 1/4"
144 1/2"
168"
192 1/2"
8CC2280F
8CC2280F
8CC2252F
8CC2250F
8CC2250F
8CC2252F
8J3246
8J3256
8J3276
8J3286
8J3256
8J3246
WHEN LOCATING BLADE, USE CENTER
HOLE ON REAR OF BRACKET, AS
SHOWN. DIMENSION SHOWN IS FROM
CENTERLINE OF MACHINE TO THIS HOLE.
0"
16 1/4"
57 1/4"
97 1/4"
137 1/4"
177 1/4"
217 1/4"
0"
37 1/4"
77 1/4"
117 1/4"
157 1/4"
197 1/4"
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
2-68
