REAR HITCH 8/23/2012 8T9012.iam/
8T4510 8X0107
8T4540
8T4550 8T4520
8X0418
8X0316
8T4530
8T0550
8T4570
8X0316
8T4530
8X0415
6-31
SECTION 6 – PARTS
1. Attach hitch frame to rear of coulter-chisel.
– Use 3/4 x 2” bolts.
2. Slide rear hitch slide into place.
3. Insert spring load pin.
– Spring and washer will be held in place by hitch channel and 3/16” cotter pin.
4. Install rear hitch swivel.
– Use pin and cotter keys provided.
