Summers Disk-Chisel - Manual (Page 56)

CC-DC DEPTH CNTRL HYD 9/12/2012
8J5520
3/4" ORB X #10 STR
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8T1060
8T1055
8T1050
8T1045
8T1040B
8T1037
8N3348 3/8 X 348"
+
8J5100 UNION
+
8N3048 3/8 X 48"
8J5510
3/4" ORB X #6 JIC(M)
8J5520
3/4" ORB X #10 STR
8D3212
3/4" ORB TIP ISO
8N4216
1/2 X 216"
8N4228
1/2 X 228"
8N4216
1/2 X 216"
8N3348
3/8 X 348"
+
8J5100 UNION
+
8N3018
3/8 X 18"
(AN ADDITIONAL 8J5100 AND
8N3060 USED ON 40')
8N3150
3/8 150"
8N6570 3/4 X 570"
+
8J5110 UNION
+
8N6060 3/4 X 60"
+
8J5110 UNION
+
8N6060 3/4 X 60"
( AN ADDITIONAL 8J5110 AND
8N6060 USED ON 40')
32'-40' DISK- / COULTER- CHISEL CASTER HYD.
(40' ADDS 8J5110
AND 8N4060)
(40' ADDS 8J5110
AND 8N4060)
8J6020
3/4"-16ORB X 10 JIC(M) 90° ADP
8J6010
3/4-16ORB X #6JIC(M) 90° ADP
8J6010
3/4-16ORB X #6JIC(M) 90° ADP
TO 8T1055
TO TRACTOR
8T1060
TOP VIEW
8T1010
POPPET
8T1008
PLASTIC PLUNGER
REPAIR KIT
2-44
SECTION 2 – HYDRAULIC SET
-UP
(32’-40’)
