32' disk-chisel and coulter-chisel layout, 32' disk-chisel 32' coulter-chisel – Summers Disk-Chisel User Manual
Page 78
DETAIL A
A
32' GANG LAYOUT
8/30/2012
9DC3212.iam/
32' DISK-CHISEL
32' COULTER-CHISEL
48"
153"
48"
153"
24 1/4"
72 1/2"
120 1/4"
180 3/4"
8CC2280F
8CC2280F
8J3286
8J3276
8J3286
8J3286
WHEN LOCATING BLADE, USE CENTER
HOLE ON REAR OF BRACKET, AS
SHOWN. DIMENSION SHOWN IS FROM
CENTERLINE OF MACHINE TO THIS HOLE.
0"
16 1/4"
57 1/4"
97 1/4"
137 1/4"
177 1/4"
0"
37 1/4"
77 1/4"
117 1/4"
157 1/4"
197 1/4"
8CC2282F
8CC2281F
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
SECTION 2 – INSTALLATION OF SHANKS AND COULTER GANGS
2-66
