SECTION 2 – SET-UP OF 24’-28’ DISK-CHISEL & COULTER-CHISEL MAIN FRAME
2-13
16. Install (8T2040) Cylinder and secure with pins as shown.
17. Attach hydraulic hose holder and tip holder with 3/4 x 1-1/4” bolt and flat washer.
18. Attach hitch jack to jack spool.
19. Remove blocks from under center frame and allow wheel assemblies to support machine. Block
tires to prevent movement.
20. Add depth control cylinder locks and storage bases.
21. Install SMV sign mounting bracket and sign at center of rear rank.
22. Install Disk Mounting Tube as shown on page 2-18.
