24'-28' transport, 24’-28’ transport assembly -9 – Summers Disk-Chisel User Manual
Page 109
DETAIL A
DETAIL B
A
B
CENTER W-TRANSPORT
7/13/2012 9CC2412H.iam/
8X0242
NY-LOCK 1/2" N
8K1100
8K7033
8X0072
1/2" X 3-3/4"
8X0203
3/8" FN
8A1156
3/8 X 4-1/16 X 5"
8T4190
8X0234
7/16" LNUT
8X0044
7/16" X 3-1/2"
8T3620
8K9106
8D9108
1/4 X 2" RP
8T1055
8T1050
8CC4325
8K5515
3/4 X 4 X 6"
8X0306
3/4" LW
8X0260
3/4" N
8T4100
8K5515
3/4 X 4 X 6"
8X0306
3/4" LW
8X0260
3/4" N
8X0044
7/16" X 3-1/2"
8X0234
7/16" LNUT
8T3640
8T3300
8L0252
8T3800
8L0252
8X0316
1" FW
8X0282
8D9524
8T4166
8CC4140
8CC4140
6-9
SECTION 6 – P
ARTS (24’-28’)
