Red Lion PXU - Manual (Page 32)

32
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
SERIAL COMMUNICATION PARAMETERS
40211 Communications Type 0 1 1 Read/Write 0 = ASCII, 1 = rtU
40212 Baud Rate 0 4 4 Read/Write 0 = 2400, 1 = 4800, 2 = 9600, 3 = 19200, 4 = 38400
40213 Data Bit 7 8 1 Read/Write 0 = 7,1 = 8
40214 Parity Bit 0 2 0 Read/Write 0 = No, 1 = Even, 2 = Odd
40215 Meter Unit Address 1 247 247 Read/Write
40216 Load Serial Settings 0 1 0 Write *
0 = No change, 1 = Load Serial Settings; * - will
read 0
SLAVE ID
41001 N/A N/A
0x524C
(“RL”)
Read Only 0x524C (“RL”)
41002 N/A N/A
0x432D
(“C-”)
Read Only 0x432D (“C-”)
41003 N/A N/A
0x5058
(“PX”)
Read Only 0x5058 (“PX”)
41004 N/A N/A
model
dependent
Read Only
0x55 (“Un”) ‘n’ - 1st output;
‘0’(0x30) = No Card installed,
‘x’ (0x78) = any output option card installed
41005 N/A N/A
model
dependent
Read Only
0x
(2nd Output): ‘0’ (0x30) = No Card installed,
‘x’ (0x78) = any output option card installed
(Options): ‘9’ = RS485/No User Inputs,
‘A’ = RS485/2 User Inputs
41006 N/A N/A
0x2020
(“ “)
Read Only 0x2020 (“ “)
41007 N/A N/A Read Only
0x0100 = Software database version number in
BCD (0x0100 = 1.00)
41008 N/A N/A 0x10 Read Only 0x10 = 16 reads
41009 N/A N/A 0x10 Read Only 0x10 = 16 writes
41010 N/A N/A 0 Read Only
