SETPOINT HIGH LIMIT
to
input range dependent
The controller has a programmable high setpoint limit value to restrict the
range of the setpoint. Set the limit so that the setpoint value cannot be set above
the safe operating area of the process.
I
13
USER INPUT FUNCTION
(Model dependent)
The controller performs the programmed User Input selection (User Input
option models), when the User terminal + is connected to User terminal -.
SELECTION
FUNCTION
DESCRIPTION
NONE
No Function
No function is performed.
r-S
Controller Status
This function can be used to start (
rUN
) and
stop (
stOp
) the control function of the
controller. When in
StOp
mode, control
output 1 and 2 are disabled and output
calculations are suspended.
SPSL
Setpoint 1 or 2
Select
This function selects (maintained action)
Setpoint 1(user inactive) or Setpoint 2 (user
active) as the active setpoint.
trnF
Auto/Manual Select
This function selects (maintained action)
Automatic (user inactive) or Manual Control
(user active).
PLOC
Program Lock
The Configuration Loop is locked, as long
as user input is active (maintained action).
ILOC
Integral Action Lock
The integral action of the PID computation
is disabled (suspended), as long as
activated (maintained action).
SPrP
Setpoint Ramp
Disable
The setpoint ramping feature is disabled, as
long as activated (maintained action). Any
time the user input is activated with a ramp
in process, ramping is aborted.
ALrS
Reset All Alarms
This function can be used to reset all of the
alarms as long as activated (maintained
action). Active alarms are reset until the
alarm condition is cleared and triggered
again (momentary action).
A1rs
Reset Alarm 1
This function can be used to reset alarm 1
as long as activated (maintained action).
An active alarm is reset until the alarm
condition is cleared and triggered again
(momentary action).
A2rS
Reset Alarm 2
This function can be used to reset alarm 2
as long as activated (maintained action).
An active alarm is reset until the alarm
condition is cleared and triggered again
(momentary action).
A3rS
Reset Alarm 3
This function can be used to reset alarm 3
as long as activated (maintained action).
An active alarm is reset until the alarm
condition is cleared and triggered again
(momentary action).
F KEY FUNCTION
The controller performs the selected F1 Key Function, when 1 is pressed.
SELECTION
FUNCTION
DESCRIPTION
NONE
No Function
No function is performed.
r-S
Controller Status
This function can be used to start (
rUN
) and
stop (
stOp
) the control function of the
controller. When in
StOp
mode, control
output 1 and 2 are disabled and output
calculations are suspended.
SPSL
Setpoint 1 or 2
Select
This function toggles (momentary action)
the controller between Setpoint 1 and
Setpoint 2.
trnF
Auto/Manual Select
This function toggles (momentary action)
the controller between Automatic and
Manual Control.
ALrS
Reset All Alarms
This function can be used to reset all of the
alarms when activated (momentary action).
The alarms will remain reset until the alarm
condition is cleared and triggered again.
A1rs
Reset Alarm 1
This function can be used to reset alarm 1
when activated (momentary action). The
alarm will remain reset until the alarm
condition is cleared and triggered again.
A2rS
Reset Alarm 2
This function can be used to reset alarm 2
when activated (momentary action). The
alarm will remain reset until the alarm
condition is cleared and triggered again.
A3rS
Reset Alarm 3
This function can be used to reset alarm 3
when activated (momentary action). The
alarm will remain reset until the alarm
condition is cleared and triggered again.
COLD JUNCTION COMPENSATION
On
OFF
This parameter turns the internal cold junction compensation on or off. For
most applications, cold junction compensation should be enabled (
On
). This
parameter does not appear if a process input type is selected.
I
I
CJC
Shaded parameters are programming/model dependent.
