PARAMETER VALUE CHART

Programmer:______________________Date:_________
Controller Number:_______ Security Code:_______

INPUT MODULE (

I

)

DISPLAY

PARAMETER

FACTORY

SETTING

USER SETTING

typE

Input Type

t-J

SCAL

Temperature Scale

°F

dCPt

Decimal Resolution

0

FLtr

Digital Filtering

bANd

Input Filter Band

1

SHFt

Shift/Offset

0

dSP1

Display Value Scaling Point 1

0

dSP2

Display Value Scaling Point 2

1000

SPLO

Setpoint Low Limit

-14

SPHI

Setpoint High Limit

212

CJC

Cold Juction Compensation

On

USr1

User1 Function

NONE

USr2

User2 Function

NONE

F1In

F1 Key Function

NONE

F2In

F2 Key Function

NONE

OUTPUT MODULE (



)

DISPLAY

PARAMETER

FACTORY

SETTING

USER SETTING

OPAC

Control Action

r1r2

CtrL

Auto Control Mode

PId

CYC1

OP1 Cycle Time

2.0

OP1L

OP 1 Power Low Limit

0.0

OP1H

OP 1 Power High Limit

100.0

IF01

Input Fail OP1 Power Level

0.0

An1L

Analog Low

0.0

An1H

Analog High

100.0

CYC2

OP2 Cycle Time

2.0

OP2L

OP 2 Power Low Limit

0.0

OP2H

OP 2 Power High Limit

100.0

IF02

Input Fail OP2 Power Level

0.0

gAN2

Relative Gain

1.00

db-2

Deadband/Overlap

2

CHYS

On/Off Control Hysteresis

2

LOCKOUT MODULE (

3C

)

DISPLAY

PARAMETER

FACTORY

SETTING

USER SETTING

SP

Setpoint

dISP

OP1

Output 1 Power

PArA

OP2

Output 2 Power

PArA

SPrP

Setpoint Ramp Rate

PArA

PId

PID Group

PArA

r-S

Controller Status

dISP

OPOF

Output Power Offset

PArA

ProP

Proportional Band

PArA

Intt

Integral Time

PArA

dErt

Derivative Time

PArA

dInt

Integration Default

LOC

AL-1

Alarm 1 Value

PArA

AL-2

Alarm 2 Value

PArA

AL-3

Alarm 3 Value

PArA

ALrS

Alarm Reset

PArA

SPSL

Setpoint Select

PArA

tUNE

Auto-Tune Code

HIdE

CtrL

Auto Control Mode

HIdE

trnf

Control Mode Transfer

HIdE

dEv

Deviation Value

dISP

CodE

Access Code

0

ALARM MODULE (

4

)

DISPLAY

PARAMETER

FACTORY

SETTING

USER SETTING

ACt1

Alarm 1 Action

NONE

Lit1

Alarm 1 Annunciator

nor

rSt1

Alarm 1 Reset Mode

Auto

Stb1

Alarm 1 Standby

NO

AL-1

Alarm 1 Value

100

IFA1

Alarm 1 Input Fail Action

OFF

ACt2

Alarm 2 Action

NONE

Lit2

Alarm 2 Annunciator

nor

rSt2

Alarm 2 Reset Mode

Auto

Stb2

Alarm 2 Standby

NO

AL-2

Alarm 2 Value

200

IFA2

Alarm 2 Input Fail Action

OFF

ACt3

Alarm 3 Action

NONE

Lit3

Alarm 3 Annunciator

nor

rSt3

Alarm 3 Reset

Auto

Stb3

Alarm 3 Standby

NO

AL-3

Alarm 3 Value

300

IFA3

Alarm 3 Input Fail Action

OFF

AHYS

Alarm Hysteresis

1

Colr

Change Display Color

OFF

SERIAL COMMUNICATIONS MODULE (

7C

)

DISPLAY

PARAMETER

FACTORY

SETTING

USER SETTING

tYPE

Communications Type

rtV

bAUd

Baud Rate

3K4

dAtA

Data Bit

PArb

Parity Bit

NO

Addr

Meter Address

247
