30
REGISTER
ADDRESS
REGISTER NAME LOW LIMIT HIGH LIMIT
FACTORY
SETTING
ACCESS COMMENTS
40053 Decimal Resolution 0 3 0 Read/Write
0 = 0 (No decimal place) 1 = 0.0, 2 = 0.00,
3 = 0.000. Temperature inputs are limited to 1
decimal point except for the thermocouple B,S,R
types, which display in whole units only (0)
40054 Digital Filtering 0 50 8 Read/Write 0 = least, 50 = most
40055 Input Filter Band 0
25(.0)° or
250 (process)
1 Read/Write 1 = 1 Display unit
40056 Shift/Offset
-99(.9)° or
999 (process)
99(.9)° or
999 (process)
0 Read/Write 1 = 1 Display unit
40057 Display Value Scaling Point 1 -999 9999 0 Read/Write 1 = 1 Display unit; Value associated with lower
range of input signal (0V, 0mA or 4mA)
40058 Display Value Scaling Point 2 -999 9999 1000 Read/Write 1 = 1 Display unit; Value associated with upper limit
of input signal (50mV, 5V, 10V, or 20mA)
40059 Setpoint Low Limit
depending on
sensor type
Upper-limit of
temperature range
-148 Read/Write 1 = 1 Display unit
40060 Setpoint High Limit
Lower-limit of
temperature
range
Depends on
sensor type
2192 Read/Write 1 = 1 Display unit
40061 Cold Junction Compensation 0 1 0 Read/Write 0 = ON, 1 = OFF
40062 User Input 1 Function 0 9 or 10 0 Read/Write
0 = NONE, 1 = Run/Stop, 2 = Setpoint 1/2 select,
3 = Auto/Manual control, 4 = PLOC, 5 = Integral
Lock, 6 = SP Ramp Disable, 7 = Reset Alarms,
8 = Rst Alm1, 9 = Rst Alm2, 10 = Rst Alm3
40063 User Input 2 Function 0 9 or 10 0 Read/Write
0 = NONE, 1 = Run/Stop, 2 = Setpoint 1/2 select,
3 = Auto/Manual control, 4 = PLOC, 5 = Integral
Lock, 6 = SP Ramp Disable, 7 = Reset Alarms,
8 = Rst Alm1, 9 = Rst Alm2, 10 = Rst Alm3
40064 F1 Key Function 0 6 or 7 0 Read/Write
0 = NONE, 1 = Run/Stop, 2 = Setpoint 1/2 select,
3 = Auto/Manual control, 4 = Reset Alarms,
5 = Rst Alm1 , 6 = Rst Alm2 , 7 = Rst Alm3
40065 F2 Key Function 0 6 or 7 0 Read/Write
0 = NONE, 1 = Run/Stop, 2 = Setpoint 1/2 select,
3 = Auto/Manual control, 4 = Reset Alarms,
5 = Rst Alm1 , 6 = Rst Alm2 , 7 = Rst Alm3
OUTPUT PARAMETERS
40081 Output Action 0 1 or 5 0 Read/Write
Single Output Model: 0 = r1, 1 = d1;
Dual Output Model: 0 = r1r2, 1 = d1r2, 2 = r1d2,
3 = d1d2, 4 = r1A2, 5 = d1A2
r = reverse acting, d = direct acting, A = Alarm 3,
numeric value indicates OP1 or OP2,
40082 Auto Control Mode 0 1 0 Read/Write 0 = PID, 1 = On-Off
40083 Output 1 Cycle Time 0 250 20 Read/Write 1 = 0.1 sec; A setting of zero will keep output off.
40084 Output 1 Power Lower Limit 0
Output 1 Power
High Limit
0 Read/Write 1 = 0.1 %
40085 Output 1 Power High Limit
Output 1 Power
Lower Limit
1000 1000 Read/Write 1 = 0.1 %
40086 Input Fail OP1 Power Level 0 1000 0 Read/Write 1 = 0.1 %
40087 Analog Out 1 Low Scaling Value -999 9999 0 Read/Write 1 = 0.1 %
40088 Analog Out 1 High Scaling Value -999 9999 1000 Read/Write 1 = 0.1 %
40089 Reserved 0
40090 Reserved 0
40091 Output 2 Cycle Time 0 250 20 Read/Write 1 = 0.1 sec; A setting of zero will keep output off.
40092 Output 2 Power Lower Limit 0
Output 2 Power
High Limit
0 Read/Write 1 = 0.1 %
40093 Output 2 Power High Limit
Output 2 Power
Lower Limit
1000 1000 Read/Write 1 = 0.1 %
40094 Input Fail OP2 Power Level 0 1000 0 Read/Write 1 = 0.1 %
40095 Relative Gain 1 9999 100 Read/Write 1 = 0.01; In combination Reverse(r) and Direct(d)
modes, this defines the gain of OP2 relative to OP1.
40096 Deadband/Overlap
-99(.9) or
-999 (process)
999(.9)° or
9999 (process)
2 Read/Write
1 = 1 Display unit; In combination Reverse(r) and
Direct(d) modes, this defines the overlap area in
which both OP1 and OP2 are active
(negative value) or the deadband area (positive
value).
40097 On/Off Control Hysteresis 2
250(.0)° or 2500
(process)
2 Read/Write 1 = 1 Display unit
