User's Guide _______________________________________________________________________
22 ___________________________________________________________________ M211501EN-C
Dimensions
1403-108
Figure 6 Probe Dimensions without Silicone Plug
1403-110
Figure 7 Probe Dimensions with Silicone Plug
1403-112
Figure 8 Electronics Housing Dimensions
1403-109
Figure 9 Attachment Bracket Dimensions
163
118.5
Screw BN 10649 M4 x 8 mm
(for 1 mm thick sheet metal
attachment)
11 21
Ш
30.
2
1.
3°
Ш
19
Ш
24.
8
Position only the filter
inside the heated chamber
163
118.5
Screw BN 10649 M4 x 8 mm
(for 1 mm thick sheet metal
attachment)
11 21
Ш
30.
2
Ш
19
2.5
Incubator’s inner wall
1.
3°
Position only the filter
inside the heated chamber
Recommended diameter
for installation tube 44 mm
M12
54.4
87
Reserve space for M12 cable
40
4 Ч Ш3.5
52
