GEN START CONTROL
Copyright 2003
© OutBack Power Systems, Inc
User Manual
.
MATE2M System Controller and Display
19009 62
nd
Ave NE, Arlington WA 98223 USA
Tel 360 435 6030 Fax 360 435 6019
Rev 1.00 03/31/04
Page 9
Currently: Auto
OFF AUTO ON OK
Pressing the
START CONTROL
screen. This screen allows the user to change the Advanced
Generator Start (AGS) mode. Modes can only be changed when Advanced Generator
Start is enabled (See section
for more information).
When an OutBack HUB is employed, the GEN START CONTROL only effects the FX
that has been programmed as the AGS PORT in the AGS menu.
Manually overrides AGS mode and shuts off the generator
Allows the MATE2M to automatically start and stop the generator
according to the settings programmed in the AGS menu
Manually overrides AGS mode and starts the generator
Returns to the point in the menu system where you entered the GEN
START CONTROL
screen
AC INPUT SOURCE
currently: CORD
GEN CORD OK
Pressing the
INPUT SOURCE
screen. This allow the user to switch between shore cord or
generator input modes.
Forces the FX to use the generator input settings
Forces the FX to use the shore cord input settings.
Returns to the point in the menu system where you entered the AC
INPUT SOURCE
screen
AC CORD AMPS ------P01
Currently: 15.0 amps
MORE LESS PORT OK
Pressing the
CORD AMPS
screen. This screen allows the user to adjust the shore cord input size.
When the
shore cord input will be increased.
will reduce the amperage that the FX is allowed to draw off the shore cord.
When a stacked system and an OutBack HUB is employed, this screen only controls
the FX pointed to by the
with a HUB, please see section
4.0 USING the MATE2M with a HUB.
