STATUS MENU
DESCONNECT
REASONS
MAIN----------------
6:54:42P
SUM-
SET DIS STATUS
MARY METERS UP PLAY
↓
STATUS/FX/PAGE1-----
choose category:
METER BATT ERROR PG2
↓
STATUS/FX/PAGE2-----
choose category:
PG1 WARN DISCON OK
↓
STATUS/FX/DISCON-P00
ac in freq NO
to high
DOWN STATUS PORT
↓
STATUS/FX/DISCON-P00
ac in freq NO
to low
DOWN STATUS PORT
↓
STATUS/FX/DISCON-P00
ac in voltage NO
> max
DOWN UP TOP PORT
↓
STATUS/FX/DISCON-P00
ac in voltage NO
< min
UP TOP PORT
↓
STATUS/FX/ERROR—----
end of error menu
UP TOP STATUS
