LOAD START
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS/PG2----
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
ADV/MATE/AGS--------
Choose category:
MUST LOAD
PG2 START RUN PG3
↓
ADV/MATE/AGS/LS-----
load start 0 kw
DOWN AGS INC DEC
↓
ADV/MATE/AGS/LS-----
load start 1 min
selay
DOWN UP INC DEC
↓
ADV/MATE/AG - S/LS----
load stop 0 kw
DOWN UP INC DEC
↓
ADV/MATE/AGS/LS-----
load sop 1 min
selay
DOWN UP INC DEC
↓
ADV/MATE/AGS/LS-----
End of LOAD START
menu
UP TOP AGS
MUST RUN
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS/PG2----
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
ADV/MATE/AGS--------
Choose category:
LOAD
T MUS
PG2 START RUN PG3
↓
ADV/MATE/AGS/MR-----
weekday: 12:00A
must run start time
DOWN AGS CHANGE
↓
ADV/MATE/AGS/MR-----
weekday: 12:00A
must run stop time
DOWN UP CHANGE
↓
ADV/MATE/AGS/MR-----
weekend: 12:00A
must run start time
DOWN UP CHANGE
↓
ADV/MATE/AGS/MR-----
weekend: 12:00A
must run stop time
DOWN UP CHANGE
↓
ADV/MATE/AGS/MR-----
End of MUST RUN
menu
UP TOP AGS
EXERCISE
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS/PG2----
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
ADV/MATE/AGS--------
Choose category:
LOAD MUST
PG2 START RUN PG3
↓
ADV/MATE/AGS--------
Choose category:
PG3 EXERCISE TMRS ADV
↓
ADV/MATE/AGS/EX-----
Exercise --
start day
DOWN AGS INC DEC
↓
ADV/MATE/AGS/EX-----
exercise 12:00A
start time
DOWN UP CHANGE
↓
ADV/MATE/AGS/EX-----
Exercise 15 min
period
DOWN AGS INC DEC
↓
ADV/MATE/AGS/EX-----
End of EXERCISE
menu
UP TOP AGS
TIMERS
