2.2.3 ‘SOFT’ Keys
The four buttons under the LCD are referred to as the ‘soft’ keys. Their operation is dependent on what their label says. The
label is the word on the bottom line of the LCD directly above the button.
Soft keys used to navigate the menus are commonly labeled , , , , or .
Soft keys that change settings are labeled either with the change they will make, such as : , , and , or if
there are more then a couple values that the setting can be changed to, and are used to mean increase and
dec
rease, respectively.
STATUS/FX/METERS—P01
Copyright 2003
© OutBack Power Systems, Inc User Manual . MATE2M System Controller and Display
19009 62 nd Ave NE, Arlington WA 98223 USA
Tel 360 435 6030 Fax 360 435 6019 Rev 1.00 03/31/04 Page 7
output: 119 vac
voltage
DOWN UP TOP PORT
In this example, pressing will take you to the next setpoint screen in
the SETUP/FX/INPUT menu.
SETUP/FX/INPUT---P00
Input setup
completed
TOP SETUP MAIN
In this example, pressing will take you to the first setpoint screen in
the SETUP/FX/INPUT menu. will return you to the SETUP/FX
screen, and
SETUP/FX/INPUT---P00
ac transfer CORD
control
DOWN CORD GEN PORT
In this example, pressing will change the FX AC transfer control to
CORD
mode. Conversely, pressing will change the FX AC transfer
control to GEN mode.
SETUP/FX/INPUT---P00
ac1/grid 60 aac
limit
DOWN INC DEC PORT
In this example, pressing or will change the numerical value of
the ac1/grid limit setting.
ADV/FX/AUX-------P00
aux output Remote
function
DOWN INC DEC PORT
In this example, there are multiple operating modes for the aux output function.
Pressing or will cycle through the available modes.
