3.0 Advanced Menu
The Advanced menu system is where most of the initial system settings are programmed. Because changing these settings
could adversely effect how the system operates, the user must input a password to enter the advanced menus. The settings
under the Advanced menu should only be changed by someone that has read and understands the specific products users
manual.
NOTE:
Not all Advanced menu screens are applicable to every model FX. An example would be a none Grid-Tie
FX may not display grid-tie parameters, or allow their adjustment.
AC POWER SYSTEM MENU
SUM- STATUS SET DIS-
MARY METERS UP PLAY
The Advanced menu is hidden and can only be accessed from the Setup menu. From
the Main menu press
press the middle two buttons simultaneously (The middle two buttons are labeled
and
SETUP INV CHGR MENU
select category:
AC IN
SEARCH LBCO LIMT PG2
At the resulting warning screen, press any of the four soft keys to continue on to the
password screen.
ADV/PASSWORD--------------
Enter the password
132
ENTER INC DEC EXIT
Using the
.
The Advanced menus allow the user to set most of the initial system setpoints for the FX, MX, and MATE. After entering the
password choose the product you would like to change the Advanced settings for.
The FX Advanced menus have categories like:
•
INV – Inverter setup
•
CHGR – Charger setpoints
•
GRID – Grid input setpoints
•
GEN – Generator input setpoints
•
AUX – FX Aux output settings
•
STACK – FX stacking setup
•
CAL – FX meter calibrations
NOTE:
Not all Advanced menu screens are applicable to every model FX. An example would be a non Grid-Tie FX
may not display grid-tie parameters, or allow their adjustment.
The MX Advanced menus only allow for the setup and control of the MX60s AUX output.
The Mate Advanced menus contain the settings for:
•
AGS – Advanced Generator Starting
These advanced settings are covered in section
5.0 Advanced Generator Start Mode
The Advanced Menu Password is 141
MATE2M System Controller and Display User Manual
Copyright 2003
© OutBack Power Systems, Inc.
19009 62
nd
Ave NE, Arlington WA 98223 USA
Page 14
Rev 1.00 03/31/04 Tel 360 435 6030 Fax 360 435 6019
