ADVANCED MENU—FX
CORD
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
↓
ADV/FX/PAGE2--------
choose category:
ADV CORD GEN PG2
↓
ADV/FX/CORD------P00
Ac usage USE
connect delay
DOWN DROP USE PORT
↓
ADV/FX/CORD------P00
ac1/grid 100 vac
lower limit
DOWN INC DEC PORT
↓
ADV/FX/CORD------P00
ac1/grid 140 vac
upper limit
DOWN INC DEC PORT
↓
ADV/FX/CORD------P00
ac1/grid 60.0 aac
input limit
DOWN INC DEC PORT
↓
ADV/FX/CORD------P00
ac1/grid
c 3 ycles
transfer delay
DOWN INC DEC PORT
↓
ADV/FX/CORD------P00
CORD programming
completed
TOP ADV MAIN
GEN
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE2--------
choose category:
PG1 CORD GEN PG3
↓
ADV/FX/GEN-------P00
Ac usage USE
connect delay
DOWN DROP USE PORT
↓
ADV/FX/GEN-------P00
ac input 00.5 min
connect delay
DOWN INC DEC PORT
↓
ADV/FX/GEN-------P00
ac2/gen 100 vac
lower limit
DOWN INC DEC PORT
↓
ADV/FX/GEN-------P00
ac2/gen 140 vac
upper limit
DOWN INC DEC PORT
↓
ADV/FX/GEN-------P00
ac2/gen 60.0 aac
input limit
DOWN INC DEC PORT
↓
ADV/FX/GEN-------P00
ac2/gen
c 3 ycles
transfer delay
DOWN INC DEC PORT
↓
ADV/FX/GEN-------P00
ac2/gen OFF
support
DOWN OFF ON PORT
↓
ADV/FX/GEN----------
GEN programming
completed
TOP ADV MAIN
AUX OUTPUT
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
↓
ADV/FX/PAGE2--------
choose category:
PG1 CORD GEN PG3
↓
ADV/FX/PAGE3--------
choose category:
PG2 AUX STACK PG4
↓
cont on next page
