5.0 MATE2M Advanced Generator Start Mode
The settings for all of the MATE2M Advanced Generator Start are under the
ADVANCED menu. The Advanced menu is hidden and can only be accessed from the
Setup menu. From the Main menu press .
AC POWER SYSTEM MENU
SUM- STATUS SET DIS-
MARY METERS UP PLAY
When the SETUP INV / CHGR MENU screen appears, press the middle two buttons
simultaneously
(The middle two buttons are labeled and
respectively)
SETUP INV CHGR MENU
select category:
AC IN
SEARCH LBCO LIMT PG2
At the resulting warning screen, press any of the four soft keys to continue on to the
password screen.
ADV/PASSWORD--------------
Enter the password
132
ENTER INC DEC EXIT
Using the and buttons, enter the advanced menu password and press
.
ADV-----------------------------
Choose product:
FX MX MATE MAIN
Choose at the Advanced menu screen.
ADV/MATE--------------------
Choose category:
AGS ADV
Choose to begin Advanced Generator Start setup.
5.1 Advanced Generator Start Mode
Advanced Generator Start (AGS) Mode utilizes the AUX output found on FX inverters and is compatible with any 2 wire start
generator. AGS allows the user to choose a variety of conditions that will start a generator by energizing the FX AUX output.
AGS will start the generator anytime one or more of the Gen Start conditions are true, and will stop the generator only when all
of the conditions are false.
After AGS starts a generator, the FX must connect to the generator within a 5 minute window. If the FX fails to connect within
5 minutes, a Genstart error is displayed by the MATE2M, and all subsequent AGS conditions will be ignored until the AGS
mode has been reset. AGS mode can be reset by using the GEN START CONTROL found by pressing the button
twice. Pressing and then resets all AGS errors or faults. The generator can also be manually started using
the GEN START CONTROL screen by pressing . If the user wants the generator to auto stop after a charge cycle is
complete, the user can press the button after the generator has been started by pressing .
The following is a discussion of all the AGS setup parameters and start condition available to the user:
