CONTROL KEYS STATUS MENU
Inv Hot Key
MATE2M System Controller and Display User Manual Copyright 2003
© OutBack Power Systems, Inc.
19009 62 nd Ave NE, Arlington WA 98223 USA
Page 22 Rev 1.00 03/31/04 Tel 360 435 6030 Fax 360 435 6019
INV
INVERTER CONTROL
currently: ON
OFF SRCH ON OK
AC IN Hot Key
AC IN
AC INPUT CONTROL
GEN AC AC
START INPUT AMPS OK
GEN START CONTROL
currently: MAN-OFF
OFF AUTO ON OK
AC INPUT SOURCE
currently: Cord
GEN CORD OK
AC CORD AMPS-----P00
Currently: 30.0 amps
MORE LESS PORT OK
Summary Screens
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
ACLOADS 0 AMPS AC
CHARGER 0 AMPS AC
ACTOTAL 0 AMPS AC
Battery Good 25.4V
- - - - - - - - - -
MX CHARGER. . . . .
Battery 25.6V
METERS
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
STATUS/FX/PAGE1-----
choose category:
METER BATT ERROR PG2
↓
INVERT P00
inv 0.0kw
chg 0.0kw buy 0.0kw
DOWN STATUS PORT
↓
STATUS/FX/METERS—P00
output 122 vac
voltage
DOWN UP TOP PORT
↓
STATUS/FX/METERS—P00
input 122 vac
voltage
DOWN UP TOP PORT
↓
STATUS/FX/METERS—P00
inverter 0.0 aac
current
DOWN UP TOP PORT
↓
STATUS/FX/METERS—P00
charger 0.0 aac
current
DOWN UP TOP PORT
↓
STATUS/FX/METERS—P00
input 0.0 aac
current
DOWN UP TOP PORT
↓
STATUS/FX/METERS—P00
FX firmware 50
revision
DOWN UP TOP PORT
↓
STATUS/FX/METERS—---
end of meter menu
UP TOP STATUS
BATTERY
MAIN----------------
6:54:42P
SUM-
SET DIS STATUS
MARY METERS UP PLAY
↓
STATUS/FX/PAGE1-----
choose category:
METER BATT ERROR PG2
↓
STATUS/FX/BATT---P00
battery 25.0 vdc
actual
DOWN STATUS PORT
↓
STATUS/FX/BATT---P00
battery 25.0 vdc
temp compensated
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
absorb 28.8 vdc
setpoint
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
absorb 01.5 hrs
time remaining
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
float 26.8 vdc
setpoint
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
float 00.8 hrs
time remaining
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
refloat 25.0 vdc
setpoint
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
equalize 28.8 vdc
setpoint
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
equalize 02.0 hrs
time remaining
DOWN UP TOP PORT
↓
STATUS/FX/BATT---P00
batt temp. 255
(not
de in gree C/F)
DOWN UP TOP STATUS
↓
STATUS/FX/BATT--—---
end of battery menu
UP TOP STATUS
