ADVANCED MENU--MATE
AGS SETUP
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
MATE/AGS/SETUP------
Ags port: 0
DOWN AGS INC DEC
↓
MATE/AGS/SETUP------
Ags enabled: NO
DOWN UP NO YES
↓
MATE/AGS/SETUP------
Ags control: MAN-OFF
DOWN UP CHANGE
↓
MATE/AGS/SETUP------
Dc genset: NO
DOWN UP NO YES
↓
MATE/AGS/SETUP------
Vdc genstop:38.0 vdc
DOWN UP INC DEC
↓
MATE/AGS/SETUP------
End of AGS SETUP
menu
UP TOP AGS
QUIET TIME
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS--------
Choose category:
VOLT QUIET
SETUP TIME START PG2
↓
MATE/AGS/QT---------
weekday: 12:00A
quiet time start
DOWN AGS CHANGE
↓
MATE/AGS/QT---------
weekday: 12:00A
quiet time stop
DOWN AGS CHANGE
↓
MATE/AGS/QT---------
weekend: 12:00A
quiet time start
DOWN AGS CHANGE
↓
MATE/AGS/QT---------
weekend: 12:00A
quiet time stop
DOWN AGS CHANGE
↓
MATE/AGS/QT---------
End of QUIET TIME
menu
UP TOP AGS
VOLTAGE START
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
MATE/AGS/VSTART-----
Volt start 24.4 vdc
24 hr setting
DOWN AGS INC DEC
↓
ATE/AGS/VSTART-----
Volt start 23.6 vdc
2 hr setting
DOWN AGS INC DEC
↓
ATE/AGS/VSTART-----
Volt start 22.0 vdc
2 min setting
DOWN AGS INC DEC
↓
MATE/AGS/VSTART-----
End of VOLT START
menu
UP TOP AGS
