ERRORS
MAIN----------------
6:54:42P
SUM-
SET DIS STATUS
MARY METERS UP PLAY
↓
STATUS/FX/PAGE1-----
choose category:
METER BATT ERROR PG2
↓
STATUS/FX/ERROR—-P00
low ac output NO
voltage
DOWN STATUS PORT
↓
STATUS/FX/ERROR—-P00
stacking NO
error detected
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
inverter NO
overtemp
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
low battery NO
voltage
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
phase loss NO
error
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
high battery NO
error
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
ac output NO
shorted
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—-P00
ac output NO
backfeed
DOWN UP TOP PORT
↓
STATUS/FX/ERROR—----
end of error menu
UP TOP STATUS
WARNINGS
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
STATUS/FX/PAGE1-----
choose category:
METER BATT ERROR PG2
↓
STATUS/FX/PAGE2-----
choose category:
PG1 WARN DISCON OK
↓
STATUS/FX/WARN---P00
ac in freq NO
to high
DOWN STATUS PORT
↓
STATUS/FX/WARN---P00
ac in freq NO
to low
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
ac in voltage NO
to high
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
ac in voltage NO
to low
DOWN UP TOP
↓
STATUS/FX/WARN---P00
ac input NO
current exceeds max
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
temperature NO
sensor fault
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
internal comm NO
error detected
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
internal fan NO
error detected
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
Air temp
204
DOWN UP TOP PORT
↓
STATUS/FX/WARN---P00
Fet temp
204
DOWN UP TOP PORT
↓
WARNINGS cont
STATUS/FX/WARN---P00
Cap temp
204
DOWN UP TOP PORT
↓
STATUS/FX/WARN------
end of warnings menu
UP TOP STATUS
