2.2.4 The ‘INV’ Hot Key
The OutBack MATE2M includes an INV “hot” key to allow direct control of the inverter from anywhere in the menu system.
The INV key is located on the right side of the MATE2M LCD display. Pressing the INV key will take you to the INVERTER
CONTROL menu section as shown below.
A green LED indicator is located above the INV key which flashes when the inverter is either in the search or power save
modes, and is on continuously when full AC output voltage is available from the inverter. When the inverter is turned off or
when the AC input source is being used, the green LED will not be illuminated.
When an OutBack HUB is employed, the INVERTER CONTROL options effect all FX inverters on the HUB.
MATE2M System Controller and Display User Manual Copyright 2003
© OutBack Power Systems, Inc.
19009 62 nd Ave NE, Arlington WA 98223 USA
Page 8 Rev 1.00 03/31/04 Tel 360 435 6030 Fax 360 435 6019
INVERTER CONTROL
currently: ON
OFF SRCH ON OK
Turns all the inverters connected to the MATE2M off
INV
Causes the inverter to begin operating in the search mode if the AC
load connected is smaller than allowed by the programming of the
search function.
Turns all the inverters connected to the MATE2M on
Returns to the point in the menu system where you entered the
INVERTER CONTROL
screen
2.2.5 The ‘AC IN’ Hot Key
The OutBack MATE2M includes an AC IN “hot” key to allow direct control of the AC input from anywhere in the menu system.
The AC IN key is located on the left side of the MATE2M LCD display.
Above the AC IN key is a yellow LED indicator which flashes when an AC source is available but not connected and which is
on continuously when the AC source is connected and in use. If no AC source is connected the yellow LED indicator will
remain off.
AC INPUT CONTROLS
GEN AC AC
START INPUT AMPS OK
AC IN
Pressing the key brings up the AC INPUT CONTROLS screen. This screen
allows the user to adjust common AC input settings and modes. When an OutBack
HUB is employed, the AC INPUT CONTROLS only effects the Master FX connected to
PORT 1. The Master then echoes the command to all of its slaves.
Controls the MATE2M Advanced Generator Starting Mode. See
Section 5.0 MATE2M Advanced Generator Starting .
Sets the input mode to CORD or GEN.
Allows the user to adjust shore cord AC input amps.
Continued on next page
