ADVANCED MENU--FX
INVERTER
Copyright 2003
© OutBack Power Systems, Inc User Manual . MATE2M System Controller and Display
19009 62 nd Ave NE, Arlington WA 98223 USA
Tel 360 435 6030 Fax 360 435 6019 Rev 1.00 03/31/04 Page 27
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
↓
ADV/FX/INVERTER—-P00
search 6
sensitivity
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—-P00
search 2 cycles
pulse length
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—-P00
search 30 cycles
pulse spacing
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—-P00
low battery
21.0 vdc
cut-out setpoint
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—-P00
low battery 25.0 vdc
cut-in setpoint
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—-P00
adjust 120 vac
output voltage
DOWN INC DEC PORT
↓
ADV/FX/INVERTER—----
reset FX to factory
defaults
DOWN MORE
↓
INVERTER cont
ADV/FX/INVERTER—-P00
choose FX port
then press next
EXIT PORT NEXT
↓
ADV/FX/INVERTER—-P00
press button 1
READY
EXIT 1 2
↓
ADV/FX/INVERTER—-P00
press button 2
READY
EXIT 1 2
↓
ADV/FX/INVERTER—-P00
press button 1
DONE
EXIT 1 2
↓
ADV/FX/INVERTER—----
reset FX to factory
defaults
DOWN MORE
↓
ADV/FX/INVERTER—----
Inverter programming
completed
TOP ADV MAIN
CHARGER
MAIN----------------
6:54:42P
SUM- STATUS SET DIS
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
↓
ADV/FX/CHARGER---P00
charger 12.0 aac
limit
DOWN INC DEC PORT
↓
ADV/FX/CHARGER------
absorb 28.8 vdc
setpoint
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
absorb 02.0 hrs
time limit
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
float 26.8 vdc
setpoint
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
float 00.5 hrs
time period
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
refloat 25.0 vdc
setpoint
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
equalize 28.8 vdc
setpoint
DOWN INC DEC PORT
↓
ADV/FX/CHARGER---P00
equalize 02.0 hrs
time period
DOWN INC DEC PORT
↓
ADV/FX/CHARGER------
Charger programming
compelted
TOP ADV MAIN
