AUX OUTPUT cont
ADV/FX/AUX-------P00
aux output OFF
control
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output AUTO
control
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output ON
control
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output Remote
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output Loadshed
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output GenAlert
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output Fault
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output Vent Fan
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output CoolFan
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output DivertDC
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
aux output DivertAC
function
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
genalert 22.0 vdc
on setpoint
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
genalert 4 min
on delay
DOWN INC DEC PORT
↓
AUX OUTPUT cont
ADV/FX/AUX-------P00
genalert 28.0 vdc
off setpoint
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
genalert 9 min
off delay
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
loadshed 22.0 vdc
off setpoint
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
ventfan 26.0 vdc
on setpoint
DO
INC DEC PORT WN
↓
ADV/FX/AUX-------P00
ventfan off 5 min
period
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
diversion 29.2 vdc
on setpoint
DOWN INC DEC PORT
↓
ADV/FX/AUX-------P00
diversion 30 sec
off delay
DOWN INC DEC PORT
↓
ADV/FX/AUX---------
Aux output
Setup completed
TOP ADV MAIN
STACKING
MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/FX/PAGE1--------
choose category:
ADV INV CHGR PG2
↓
STACKING cont
ADV/FX/PAGE2--------
choose category:
PG1 GRID GEN PG3
↓
ADV/FX/PAGE3--------
choose category:
PG2 AUX STAC PG4
K
↓
ADV/FX/STACK-----P00
stack 1-2PH Master
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
stack Clasic Slave
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
stack OB Slave L1
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
stack OB Slave L2
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
stack 3PH Master
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
stack 3PH Slave
phase
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
power save level 0
master adjust only
DOWN INC DEC PORT
↓
ADV/FX/STACK-----P00
power save level 1
slave adjust only
DOWN INC DEC PORT
↓
ADV/FX/STACK--------
Stacking setup
completed
TOP ADV MAIN
