MAIN----------------
6:54:42P
SUM- STATUS S
DIS ET
MARY METERS UP PLAY
↓
SETUP INV/CHGR MENU
choose category:
AC IN
SEARCH LBCO LIMT PG2
↓ ↓
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
↓ ↓ ↓ ↓
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
↓
ADV-----------------
choose product:
FX MX MATE MAIN
↓
ADV/MATE------------
Choose category:
AGS ADV
↓
ADV/MATE/AGS/PG2----
Choose category:
QUIET VOLT
SETUP TIME START PG2
↓
ADV/MATE/AGS--------
Choose category:
LOAD MUST
PG2 START RUN PG3
↓
ADV/MATE/AGS--------
Choose category:
PG3 EXERCISE TMRS ADV
↓
ADV/MATE/AGS/TIMERS--
agsstate: 0
DOWN AGS
↓
ADV/MATE/AGS/TIMERS--
genfault: 0
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
24 hr 1440 min
vs time
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
2 hr 120 min
vs time
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
2 min 2 min
vs time
DOWN UP
↓
TIMERS cont.
ADV/MATE/AGS/TIMERS--
Lsstart timer 0 min
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
Lsstop timer 0 min
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
vdcstop timer 0 min
DOWN UP
↓
ADV/MATE/AGS/TIMERS--
exstop timer 0 min
DOWN UP
↓
ADV/MATE/AGS/TIMERS-
End of TIMERS
menu
UP TOP AGS
